Setup Local Repository In Ubuntu 15.04

by

Please shareShare on Facebook448Share on Google+2Tweet about this on Twitter38Share on LinkedIn4Share on Reddit1Digg thisShare on StumbleUpon1Share on VKBuffer this page

Why Local repository is important?

As a System administrator, you have to install software, security updates and fixes often in all systems. Obviously, it will consume more Internet bandwidth. So instead of downloading and installing applications every time in all systems from the Ubuntu repositories, it is good idea to save all applications in a local server in your LAN and distribute them to the other Ubuntu systems when required. Having a local repository is really fast and efficient way, because all required applications will be transferred over the fast LAN connection from your local server. So that it will save the Internet bandwidth and ultimately it reduces the annual cost of Internet.

In this tutorial, I will show you how to setup local repository in Ubuntu 15.04 server in two methods.

  1. APT-Mirror ;
  2. APT-Cacher.

Both methods are very easy to set up and configure.

All you need is sufficient hard drive space. At least 50GB or more free space in your local or external hard drive is recommended. Also, you can use an external hard drive to setup a portable repository. So, you can use the portable repository on multiple locations in your LAN.

Method 1: APT-Mirror

In this method, we are going to pull all packages from the public repository (Ubuntu global server) and save them in our local Ubuntu server hard drive.

First install Apache server. Apache web server is important to share the packages over the network.

sudo apt-get install apache2

Now, install APT-Mirror using command:

sudo apt-get install apt-mirror

Now, create a directory to save all packages.

For example, let us create a directory called “/myrepo”. We are going to save all packages in this directory:

sudo mkdir /myrepo

Now, open the file /etc/apt/mirror.list file,

sudo vi /etc/apt/mirror.list

Add the line: set base_path    /myrepo

############# config ##################
#
# set base_path /var/spool/apt-mirror

set base_path /myrepo

#
# set mirror_path $base_path/mirror
# set skel_path $base_path/skel
# set var_path $base_path/var
# set cleanscript $var_path/clean.sh
# set defaultarch <running host architecture>
# set postmirror_script $var_path/postmirror.sh
# set run_postmirror 0
set nthreads 20
set _tilde 0
#
############# end config ##############

deb http://archive.ubuntu.com/ubuntu trusty main restricted universe multiverse
deb http://archive.ubuntu.com/ubuntu trusty-security main restricted universe multiverse
deb http://archive.ubuntu.com/ubuntu trusty-updates main restricted universe multiverse
#deb http://archive.ubuntu.com/ubuntu trusty-proposed main restricted universe multiverse
#deb http://archive.ubuntu.com/ubuntu trusty-backports main restricted universe multiverse

deb-src http://archive.ubuntu.com/ubuntu trusty main restricted universe multiverse
deb-src http://archive.ubuntu.com/ubuntu trusty-security main restricted universe multiverse
deb-src http://archive.ubuntu.com/ubuntu trusty-updates main restricted universe multiverse
#deb-src http://archive.ubuntu.com/ubuntu trusty-proposed main restricted universe multiverse
#deb-src http://archive.ubuntu.com/ubuntu trusty-backports main restricted universe multiverse

clean http://archive.ubuntu.com/ubuntu

In the above configuration file, you can add the Ubuntu source lists depending upon the distribution you use.

For this tutorial, I use the default source list. Change them as per your requirements.

If you use both 32bit and 64bit architectures, you should name them separately in the above file. For example, if you use 32bit architecture, the lines should start with deb-i386 and for 64bit, the lines should start as deb-amd64. Clear? Well, once you saved the configuration file, populate your repository using the following command:

sudo apt-mirror

Sample output:

Downloading 162 index files using 20 threads...
Begin time: Wed Aug 5 16:09:16 2015
[20]... [19]... [18]... [17]... [16]... [15]... [14]... [13]... [12]... [11]... [10]... [9]... [8]... [7]... [6]... [5]... [4]...

Now the packages from the Ubuntu public repositories are being pulled and saved to your local directory (In our case it’s /myrepo). Depending upon your Internet speed, it will take hours.

You can cancel this process at any time. When you start it again, it will resume the downloading process where you left it off.  I strongly advise you to use a fast broadband Internet connection.

You don’t have to run this command every day to get new softwares/updates. You can schedule this process using a cron job. So your machine will automatically run the apt-mirror command on a regular daily basis and will keep your repository up-to-date.

To do that, edit file /etc/cron.d/apt-mirror,

sudo vi /etc/cron.d/apt-mirror

Uncomment the line shown in bold:

#
# Regular cron jobs for the apt-mirror package
#
0 4 * * * apt-mirror /usr/bin/apt-mirror > /var/spool/apt-mirror/var/cron.log

As per the above example, the cron job will run every day morning 4am and will start to download the packages.

As I mentioned above, all downloaded packages are saved in “/myrepo” directory on our local server.

Let us have a look under the /myrepo directory to make sure the packages are downloaded as shown below:

ls /myrepo/

Sample output:

mirror  skel  var

Now the contents of /myrepo directory should be made available over HTTP (web) to our clients. To do that, simply create a symbolic link to the /myrepo directory:

cd /myrepo/
sudo ln -s /myrepo/mirror/us.archive.ubuntu.com/ubuntu/ ubuntu

Please note: I made this article only for the testing purpose. So I didn’t download the whole public repository. I canceled the download process after a couple of minutes.

Client Configuration

It’s quite easy to configure in client side. Just open your client systems /etc/apt/sources.list file,

sudo vi /etc/apt/sources.list

and add your local repository path:

[...]
deb http://192.168.1.102/ubuntu trusty universe
deb http://192.168.1.102/ubuntu trusty main restricted
deb http://192.168.1.102/ubuntu trusty-updates main restricted
[...]

That’s it. Here 192.168.1.102 is my Ubuntu server IP address.

Now, update the sources list using command:

sudo apt-get update

Finally, install packages of your choice using command:

sudo apt-get install <package-name>

That’s it. The clients need not to be connected to the Internet to download packages. Instead, it will get all packages and updates from your Ubuntu server’s local repository.

Method 2: APT-Cacher

APT-Cacher is different from APT-Mirror. It does not mirror the entire repository contents. Instead, It saves the packages requested by the clients on your local network and make them available to the rest of the clients for future use.

First install Apache server. This is required to share the packages to your Ubuntu clients over the network:

sudo apt-get install apache2

Now install APT-Cacher.

sudo apt-get install apt-cacher

Choose daemon to run as a standalone daemon and click OK.

sk@server: -myrepo_001

Now, Edit file /etc/default/apt-cacher,

sudo vi /etc/default/apt-cacher

and set autostart=1 if it is 0, else leave as it is.

# apt-cacher daemon startup configuration file

# Set to 1 to run apt-cacher as a standalone daemon, set to 0 if you are going
# to run apt-cacher from /etc/inetd or in CGI mode (deprecated).  Alternatively,
# invoking "dpkg-reconfigure apt-cacher" should do the work for you.
#
AUTOSTART=1

# extra settings to override the ones in apt-cacher.conf
# EXTRAOPT=" daemon_port=3142 limit=30 "

You can also allow or deny the no of hosts to access the cache (packages).

To do that, open the /etc/apt-cacher/apt-cacher.conf file.

sudo vi /etc/apt-cacher/apt-cacher.conf

Uncomment and update the value for allowed_hosts to match the individual hosts. Here I allowed systems from 192.168.1.20 to 192.168.1.30.

[...]
## Uncomment and set the IP range ##
allowed_hosts = 192.168.1.20 - 192.168.1.30
#denied_hosts =
[...]

After completing all the steps, restart apache2 service:

sudo systemctl restart apache2

Or,

sudo service apache2 restart

Client Side Configuration

Now, create a file called /etc/apt/apt.conf.d/01proxy:

sudo nano /etc/apt/apt.conf.d/01proxy

Add the following line:

Acquire::http::Proxy "http://192.168.1.102:3142";

Here, 192.168.1.102 is my Ubuntu local repository server’s IP address. Replace the IP address with your server IP address.

Now, update the sources list using command:

sudo apt-get update

Finally, install packages of your choice using command:

sudo apt-get install <package-name>

That’s it.

Conclusion

Due to lack of resources, time and Internet bandwidth, I didn’t completely test both methods. As far as I know, both methods should work fine and they are highly recommended to save your Internet bandwidth. Although, both methods are pretty easy to configure and maintain. You don’t need to be a master In Linux to setup local repository. Give it a try, you won’t be disappointed.

Good luck!
