From the wikipedia,
Elastix is an unified communications server software that brings together IP PBX, email, IM, faxing and collaboration functionality. It has a Web interface and includes capabilities such as a call center software with predictive dialing. The Elastix functionality is based on open source projects including Asterisk, FreePBX, HylaFAX, Openfire and Postfix. Those packages offer the PBX, fax, instant messaging and email functions, respectively.
- Minimum Storage Capacity: 80 GB
- RAM: 2 GB
- CPU: Core i3 or better
Download ISO Image of Elastix Unified Communication Server from Following Link:
Make a bootable usb or burn iso image to DVD, Boot from device and Install.
At the boot prompt, press Enter.
Change the default language, press enter.
We have selected us pattern, press enter.
Recreate partitions, press yes and then press enter.
Select Installed Hard Disk, press enter.
Apply Changes and review your partition table.
Configure Network Interface, press Yes.
Select protocols you wants to have with your VoIP Server.
Assign IP address, in our scenario it will be 192.168.1.5.
Latest Elastix Distro also support IPv6, leave it as default.
Provide Gateway IP Address and DNS Address, press OK.
Provide hostname, in out case it will be ‘voip.unixmen.com’, press ok.
Select your time zone, press ok.
Provide password to the root user, our will be ‘[email protected]’.
The System will check dependencies, Then it will start installation packages automatically.
This step may take some time during installation process, System will automatically reboot after completion of this step, do not interrupt this boot process, Server will automatically ask for Mysql password, assign that password (our password is ‘[email protected]’).
In next step it will ask for admin password, this password will be required when you have to log in server via web browser (our is ‘[email protected]’).
After completion of installation process, server will be prompted with a terminal, login with username ‘root’ and provide password for root user.
Congratulation! installation is done.
Now open browser from remote system and type ip_address of elastix to open management console of server. (our scenario ip will be 192.168.1.5).
Login with ‘admin’ user and provide password then login, a dash board will appear, now you can manage all of your messaging, VoIP, Mail Services.
Congratulations!! you have installed Elastix unified Communication Service, Explore all of the available service, with Mail Services you can add domains, can configure mail accounts, and provide mail addresses as per your need, similarly you can handle your PBX or FAX etc. services.
That’s it. Have Fun!!
