RHCSA module 2 – Operating Red Hat Enterprise Server 7

Operating Red Hat  Enterprise Server 7 – An introduction

This is the continuation part of RHCSA exam guide, this module will include all of the tools, services, commands required for operating Red Hat Enterprise Linux 7. To handle a Red Hat Linux server a skills is required to monitor various processes, to handle various software and to schedule backups to that catastrophic situations can be avoided. It is possible that you can get out of storage disk storage therefore you must learn how to handle these storage device, and add or remove extra disk space if required.

Have a look on recently published articles in RHCSA series

http://www.unixmen.com/everything-know-rhcsa-certification/

http://www.unixmen.com/basics-must-know-rhcsa-exam-preparation/

http://www.unixmen.com/learn-man-vim-editor-file-globbing-rhcsa/

http://www.unixmen.com/learn-file-management-commnad-line-required-rhcsa/

http://www.unixmen.com/hard-soft-links-user-group-management-rhcsa/



 What you will learn in this module of RHCSA curriculum?

After finish this module candidate will be able to monitor processes, prioritise any process, manage, install uninstall or update software with resolving the dependencies. Further a candidate will schedule tasks with the help of cron and at commands, run virtual machines with kvm virtualisation utility, mange logs and will be handle to manage hard disk partitioning, disk formatting, adding or removing of any new hard disk with the help of Logical Volume Manager or LVM utility.

What topics are covered in module-2 of RHCSA curriculum?

  1. Process management in RHEL 7.
  2. software managing using yum in RHEL 7.
  3. Virtualization using KVM in RHEL 7.
  4. Job scheduling with cron and at in RHEL 7.
  5. Log management in RHEL 7.
  6. Disk management with disk partitioning utilities in RHEL 7.
  7. LVM management in RHEL 7.

    1. Process management in RHEL 7

Hundred of processes start when system is booted on.  You can monitor currently running processes with following command

# ps aux

Selection_039

Start some process on terminal

# firefox

Now terminal will engaged till the process is on, to send this process to background press ‘control+z’. See background process with following command.

# bg

Selection_040 To see child parent process relationship in running processes use

# ps fax

Selection_041

To see memory status of the system (-m option will display output in megabyte)

# free -m

Output

total used free shared buff/cache available
Mem: 1119 410 289 7 419 540
Swap: 819 0 819

Get the uptime of cpu alongwith average cpu load

Selection_042

To list busy most process which are consuming maximum resources use top

# top

Selection_043

You can watch cpu, memory and swap usages status as live.

Assume we wants to kill a process firefox, use killall command

 # killall firefox

Kill a process by pid.

Let us wants to kill a process with process id 11, as shown with top command.

# kill -9 11

Generally processes are initiated with a same level of priority which is by default set to a value of 20, have a look in top command.

Selection_045

You may need to change the priority of some process to make it more preferred or you may need to make it to be some lesser priority process, this can be achieved by nicing a process, these values can be between -20 to 20, more negative value means more prior process.

use top command, and press r to renice a process.

Selection_046

Let us renice sshd process with pid 2689

Selection_047

Make that value to 0

Selection_048

See the nice value of sshd now, it is a preferred process now

Selection_050

Define process renicing from terminal command line. Change value of sshd service which has a PID value of 2689 in our example.

# renice -n 20 -p 2689

Use nice to set value for some new process, define nice value after -n option, for more detail use

nice –help

# nice -n 10 dd if=/dev/zero of=/dev/null &

Have a look with top that nice value is set to 10.

# top

Selection_0512. managing software in RHEL 7 using yum.

A good article to manage yum in Red Hat Linux is already published with unixmen.com, link of the article is provided below, that article is sufficient to make you understand yum in RHEL 7.

Managing Software Packages with yum in RHEL7/CENTOS7

3. Virtualization using KVM in RHEL 7

KVM is a fully open source and complete virtualisation software, it consists of kvm.ko the loadable kernel module, it can run multiple virtual machines without modifying the host configurations.

Install kvm package

# yum install kvm libvirt virt-manager qemu-kvm

Verify whether, kvm is active or not

# systemctl status libvirtd

Selection_052Get virtualisation shell

# virsh

A new console for kvm virtualisation will get open, use help for more options.

List existing virtaul machines running on server

# virsh list



Selection_054

All of the configuration file of kvm virtualisation are stored in /etc/libvirt/, each virtual machines get its configuration file generated automatically.

To create a new virtual machine

#virt-manager

Create a new machine

Selection_055

Browse for Image OS image, define ram size

Selection_057



Selection_056

Define disk space

Selection_057

Configure and boot

Selection_060

Use following command to show installed vm

# virsh list --all
 Id Name State
----------------------------------------------------
 - centos7.0 shut off

To shut down running virtual machine

# virsh destroy centos7.0

Manage Hardware configuration of virtual machine in virt-manager

Selection_061

For more details you can access official kvm link

http://www.linux-kvm.org/page/Main_Page

4. Job scheduling with cron and at in RHEL 7

i. Using cron to handle job scheduling in Red Hat Linux 7

To automate administrative tasks,a task scheduler is required, cron and at utilities are available with Linux to schedule automated scripts or commands, cron is used when need to perform certain automation tasks on daily/hourly/weekly or on some regular time period, but at command is used when you need to perform some task once at a defined time.

Cron configuration files is /etc/crontab

# vim /etc/crontab

Sample output

SHELL=/bin/bash
PATH=/sbin:/bin:/usr/sbin:/usr/bin
MAILTO=root

# For details see man 4 crontabs

# Example of job definition:
# .---------------- minute (0 - 59)
# | .------------- hour (0 - 23)
# | | .---------- day of month (1 - 31)
# | | | .------- month (1 - 12) OR jan,feb,mar,apr ...
# | | | | .---- day of week (0 - 6) (Sunday=0 or 7) OR sun,mon,tue,wed,thu,fri,sat
# | | | | |
# * * * * * user-name command to be executed

You never put your scheduling in this file, avoiding editing that file.

Schedule cronjob for a user

time format is like [minute] [hour] [day of the month] [month] [day of the week]

Add a job in cron

# crantab -e

Get backup of /home directory daily at 5 pm daily using crontab -e

0 17  * * *  tar cfz /root/home.tgz /home

List what cron jobs are scheduled on system

# crontab -l

Selection_062

Schedule back on specific month

* * * march,april,may * cp /etc/named.* /root/backup

Schedule task after every 30 minutes

*/30 * * * *  rm  -rf /tmp/*

Another method of managing cron jobs is to use /etc/cron.d/ directory

# cd /etc/cron.d

In this file you can put files with any name you desire and define your cron job in defined format.

Selection_063

Have a look in some sample file

# vim sa-update

Selection_064

You can define your own job schedules using /etc/cron.d/ directory. Use man or help toolsto get more details on cronjob.

ii. Using at to handle job scheduling in Red Hat Linux 7

Have a look on current time

# date
Fri Jun 10 13:03:44 EDT 2016

Log hello world suppose at 13:10 using at command, define time with at command, press enter, give command, press Ctrl+D to save and quit.

# at 13:10
at> logger hellow world
at> <EOT>
job 2 at Fri Jun 10 13:10:00 2016

Check logs

# tail -f /var/log/messages

Selection_065

With at you can manage various time specific tasks with at.

Conclusion

Three chapters of module 2 of RHCSA we will cover in next topic, in which we we will discuss disk management with various command line tools available, creating and managing LVM based disk partitions. Log management is another important aspect of Linux administration therefore we will discuss that part too in detail in next and last article of module-2 of RHCSA curriculum.
