Install and using netstat in Linux

How to install netstat

netstat is a useful tool for checking your network configuration and activity. It is in fact a collection of several tools lumped together.

download

Install “net-tools” package using yum

[[email protected] ~]$ sudo yum install net-tools
Loaded plugins: fastestmirror
Loading mirror speeds from cached hostfile
* base: centos.mirror.secureax.com
* extras: centos.mirror.secureax.com
* updates: centos.mirror.secureax.com
Resolving Dependencies
--> Running transaction check
---> Package net-tools.x86_64 0:2.0-0.17.20131004git.el7 will be installed
--> Finished Dependency Resolution
Dependencies Resolved
===============================================================================
Package         Arch         Version                          Repository  Size
================================================================================
Installing:
net-tools       x86_64       2.0-0.17.20131004git.el7         base       304 k
Transaction Summary
================================================================================
Install  1 Package
Total download size: 304 k
Installed size: 917 k
Is this ok [y/d/N]: y
Downloading packages:
net-tools-2.0-0.17.20131004git.el7.x86_64.rpm              | 304 kB   00:00
Running transaction check

Running transaction test
Transaction test succeeded
Running transaction
Installing : net-tools-2.0-0.17.20131004git.el7.x86_64                    1/1
Verifying  : net-tools-2.0-0.17.20131004git.el7.x86_64                    1/1
Installed:
net-tools.x86_64 0:2.0-0.17.20131004git.el7



Complete!



The netstat Command

Displaying the Routing Table

When you invoke netstat with the –r flag, it displays the kernel routing table in the way we’ve been doing with route. On vstout, it produces:

# netstat -nr

 Kernel IP routing table
 Destination   Gateway      Genmask         Flags  MSS Window  irtt Iface
 127.0.0.1     *            255.255.255.255 UH       0 0          0 lo
 172.16.1.0    *            255.255.255.0   U        0 0          0 eth0
 172.16.2.0    172.16.1.1   255.255.255.0   UG       0 0          0 eth0

The –n option makes netstat print addresses as dotted quad IP numbers rather than the symbolic host and network names. This option is especially useful when you want to avoid address lookups over the network (e.g., to a DNS or NIS server).

The second column of netstat‘s output shows the gateway to which the routing entry points. If no gateway is used, an asterisk is printed instead. The third column shows the “generality” of the route, i.e., the network mask for this route. When given an IP address to find a suitable route for, the kernel steps through each of the routing table entries, taking the bitwise AND of the address and the genmask before comparing it to the target of the route.

The fourth column displays the following flags that describe the route:

G The route uses a gateway.
U The interface to be used is up.
H Only a single host can be reached through the route. For example, this is the case for the loopback entry 127.0.0.1.
D This route is dynamically created. It is set if the table entry has been generated by a routing daemon like gated or by an ICMP redirect message
M This route is set if the table entry was modified by an ICMP redirect message.
! The route is a reject route and datagrams will be dropped.



The next three columns show the MSS, Window and irtt that will be applied to TCP connections established via this route. The MSS is the Maximum Segment Size and is the size of the largest datagram the kernel will construct for transmission via this route. The Window is the maximum amount of data the system will accept in a single burst from a remote host. The acronym irtt stands for “initial round trip time.” The TCP protocol ensures that data is reliably delivered between hosts by retransmitting a datagram if it has been lost. The TCP protocol keeps a running count of how long it takes for a datagram to be delivered to the remote end, and an acknowledgement to be received so that it knows how long to wait before assuming a datagram needs to retransmitted; this process is called the round-trip time. The initial round-trip time is the value that the TCP protocol will use when a connection is first established. For most network types, the default value is okay, but for some slow networks, notably certain types of amateur packet radio networks, the time is too short and causes unnecessary retransmission. The irtt value can be set using the route command. Values of zero in these fields mean that the default is being used.

Finally, the last field displays the network interface that this route will use.

Displaying Interface Statistics

When invoked with the –i flag, netstat displays statistics for the network interfaces currently configured. If the –a option is also given, it prints all interfaces present in the kernel, not only those that have been configured currently. On vstout, the output from netstat will look like this:

# netstat -i
 Kernel Interface table
 Iface MTU Met  RX-OK RX-ERR RX-DRP RX-OVR  TX-OK TX-ERR TX-DRP TX-OVR Flags
 lo      0   0   3185      0      0      0   3185      0      0      0 BLRU
 eth0 1500   0 972633     17     20    120 628711    217      0      0 BRU

The MTU and Met fields show the current MTU and metric values for that interface. The RX and TX columns show how many packets have been received or transmitted error-free (RX-OK/TX-OK) or damaged (RX-ERR/TX-ERR); how many were dropped (RX-DRP/TX-DRP); and how many were lost because of an overrun (RX-OVR/TX-OVR).

The last column shows the flags that have been set for this interface. These characters are one-character versions of the long flag names that are printed when you display the interface configuration with ifconfig:

B A broadcast address has been set.
L This interface is a loopback device.
M All packets are received (promiscuous mode).
O ARP is turned off for this interface.
P This is a point-to-point connection.
R Interface is running.
U Interface is up.



Displaying Connections

netstat supports a set of options to display active or passive sockets. The options –t, –u, –w, and –x show active TCP, UDP, RAW, or Unix socket connections. If you provide the –a flag in addition, sockets that are waiting for a connection (i.e., listening) are displayed as well. This display will give you a list of all servers that are currently running on your system.

Invoking netstat -ta on vlager produces this output:

$ netstat -ta
 Active Internet Connections
 Proto Recv-Q Send-Q Local Address    Foreign Address    (State)
 tcp        0      0 *:domain         *:*                LISTEN
 tcp        0      0 *:time           *:*                LISTEN
 tcp        0      0 *:smtp           *:*                LISTEN
 tcp        0      0 vlager:smtp      vstout:1040        ESTABLISHED
 tcp        0      0 *:telnet         *:*                LISTEN
 tcp        0      0 localhost:1046   vbardolino:telnet  ESTABLISHED
 tcp        0      0 *:chargen        *:*                LISTEN
 tcp        0      0 *:daytime        *:*                LISTEN
 tcp        0      0 *:discard        *:*                LISTEN
 tcp        0      0 *:echo           *:*                LISTEN
 tcp        0      0 *:shell          *:*                LISTEN
 tcp        0      0 *:login          *:*                LISTEN

This output shows most servers simply waiting for an incoming connection. However, the fourth line shows an incoming SMTP connection from vstout, and the sixth line tells you there is an outgoing telnetconnection to vbardolino.

Using the –a flag by itself will display all sockets from all families.

Top 20 command netstat for network management

  1. Listing all the LISTENING Ports of TCP and UDP connections

Listing all ports (both TCP and UDP) using netstat -a option.

# netstat -a | more

Active Internet connections (servers and established)
 Proto Recv-Q Send-Q Local Address               Foreign Address             State
 tcp        0      0 *:sunrpc                    *:*                         LISTEN
 tcp        0     52 192.168.0.2:ssh             192.168.0.1:egs             ESTABLISHED
 tcp        1      0 192.168.0.2:59292           www.gov.com:http            CLOSE_WAIT
 tcp        0      0 localhost:smtp              *:*                         LISTEN
 tcp        0      0 *:59482                     *:*                         LISTEN
 udp        0      0 *:35036                     *:*
 udp        0      0 *:npmp-local                *:*

Active UNIX domain sockets (servers and established)
 Proto RefCnt Flags       Type       State         I-Node Path
 unix  2      [ ACC ]     STREAM     LISTENING     16972  /tmp/orbit-root/linc-76b-0-6fa08790553d6
 unix  2      [ ACC ]     STREAM     LISTENING     17149  /tmp/orbit-root/linc-794-0-7058d584166d2
 unix  2      [ ACC ]     STREAM     LISTENING     17161  /tmp/orbit-root/linc-792-0-546fe905321cc
 unix  2      [ ACC ]     STREAM     LISTENING     15938  /tmp/orbit-root/linc-74b-0-415135cb6aeab



  1. Listing TCP Ports connections

Listing only TCP (Transmission Control Protocol) port connections using netstat -at.

# netstat -at

Active Internet connections (servers and established)
 Proto Recv-Q Send-Q Local Address               Foreign Address             State
 tcp        0      0 *:ssh                       *:*                         LISTEN
 tcp        0      0 localhost:ipp               *:*                         LISTEN
 tcp        0      0 localhost:smtp              *:*                         LISTEN
 tcp        0     52 192.168.0.2:ssh             192.168.0.1:egs             ESTABLISHED
 tcp        1      0 192.168.0.2:59292           www.gov.com:http            CLOSE_WAIT



  1. Listing UDP Ports connections

Listing only UDP (User Datagram Protocol ) port connections using netstat -au.

# netstat -au

Active Internet connections (servers and established)
 Proto Recv-Q Send-Q Local Address               Foreign Address             State
 udp        0      0 *:35036                     *:*
 udp        0      0 *:npmp-local                *:*
 udp        0      0 *:mdns                      *:*



  1. Listing all LISTENING Connections

Listing all active listening ports connections with netstat -l.

# netstat -l

Active Internet connections (only servers)
 Proto Recv-Q Send-Q Local Address               Foreign Address             State
 tcp        0      0 *:sunrpc                    *:*                         LISTEN
 tcp        0      0 *:58642                     *:*                         LISTEN
 tcp        0      0 *:ssh                       *:*                         LISTEN
 udp        0      0 *:35036                     *:*
 udp        0      0 *:npmp-local                *:*

Active UNIX domain sockets (only servers)
 Proto RefCnt Flags       Type       State         I-Node Path
 unix  2      [ ACC ]     STREAM     LISTENING     16972  /tmp/orbit-root/linc-76b-0-6fa08790553d6
 unix  2      [ ACC ]     STREAM     LISTENING     17149  /tmp/orbit-root/linc-794-0-7058d584166d2
 unix  2      [ ACC ]     STREAM     LISTENING     17161  /tmp/orbit-root/linc-792-0-546fe905321cc
 unix  2      [ ACC ]     STREAM     LISTENING     15938  /tmp/orbit-root/linc-74b-0-415135cb6aeab



  1. Listing all TCP Listening Ports

Listing all active listening TCP ports by using option netstat -lt.

# netstat -lt

Active Internet connections (only servers)
 Proto Recv-Q Send-Q Local Address               Foreign Address             State
 tcp        0      0 *:dctp                      *:*                         LISTEN
 tcp        0      0 *:mysql                     *:*                         LISTEN
 tcp        0      0 *:sunrpc                    *:*                         LISTEN
 tcp        0      0 *:munin                     *:*                         LISTEN
 tcp        0      0 *:ftp                       *:*                         LISTEN
 tcp        0      0 localhost.localdomain:ipp   *:*                         LISTEN
 tcp        0      0 localhost.localdomain:smtp  *:*                         LISTEN
 tcp        0      0 *:http                      *:*                         LISTEN
 tcp        0      0 *:ssh                       *:*                         LISTEN
 tcp        0      0 *:https                     *:*                         LISTEN



  1. Listing all UDP Listening Ports

Listing all active listening UDP ports by using option netstat -lu.

# netstat -lu

Active Internet connections (only servers)
 Proto Recv-Q Send-Q Local Address               Foreign Address             State
 udp        0      0 *:39578                     *:*
 udp        0      0 *:meregister                *:*
 udp        0      0 *:vpps-qua                  *:*
 udp        0      0 *:openvpn                   *:*
 udp        0      0 *:mdns                      *:*
 udp        0      0 *:sunrpc                    *:*
 udp        0      0 *:ipp                       *:*
 udp        0      0 *:60222                     *:*
 udp        0      0 *:mdns                      *:*



  1. Listing all UNIX Listening Ports

Listing all active UNIX listening ports using netstat -lx.

# netstat -lx

Active UNIX domain sockets (only servers)
 Proto RefCnt Flags       Type       State         I-Node Path
 unix  2      [ ACC ]     STREAM     LISTENING     4171   @ISCSIADM_ABSTRACT_NAMESPACE
 unix  2      [ ACC ]     STREAM     LISTENING     5767   /var/run/cups/cups.sock
 unix  2      [ ACC ]     STREAM     LISTENING     7082   @/tmp/fam-root-
 unix  2      [ ACC ]     STREAM     LISTENING     6157   /dev/gpmctl
 unix  2      [ ACC ]     STREAM     LISTENING     6215   @/var/run/hald/dbus-IcefTIUkHm
 unix  2      [ ACC ]     STREAM     LISTENING     6038   /tmp/.font-unix/fs7100
 unix  2      [ ACC ]     STREAM     LISTENING     6175   /var/run/avahi-daemon/socket
 unix  2      [ ACC ]     STREAM     LISTENING     4157   @ISCSID_UIP_ABSTRACT_NAMESPACE
 unix  2      [ ACC ]     STREAM     LISTENING     60835836 /var/lib/mysql/mysql.sock
 unix  2      [ ACC ]     STREAM     LISTENING     4645   /var/run/audispd_events
 unix  2      [ ACC ]     STREAM     LISTENING     5136   /var/run/dbus/system_bus_socket
 unix  2      [ ACC ]     STREAM     LISTENING     6216   @/var/run/hald/dbus-wsUBI30V2I
 unix  2      [ ACC ]     STREAM     LISTENING     5517   /var/run/acpid.socket
 unix  2      [ ACC ]     STREAM     LISTENING     5531   /var/run/pcscd.comm



  1. Showing Statistics by Protocol

Displays statistics by protocol. By default, statistics are shown for the TCP, UDP, ICMP, and IP protocols. The -s parameter can be used to specify a set of protocols.

# netstat -s

Ip:
 2461 total packets received
 0 forwarded
 0 incoming packets discarded
 2431 incoming packets delivered
 2049 requests sent out
 Icmp:
 0 ICMP messages received
 0 input ICMP message failed.
 ICMP input histogram:
 1 ICMP messages sent
 0 ICMP messages failed
 ICMP output histogram:
 destination unreachable: 1
 Tcp:
 159 active connections openings
 1 passive connection openings
 4 failed connection attempts
 0 connection resets received
 1 connections established
 2191 segments received
 1745 segments send out
 24 segments retransmited
 0 bad segments received.
 4 resets sent
 Udp:
 243 packets received
 1 packets to unknown port received.
 0 packet receive errors
 281 packets sent



  1. Showing Statistics by TCP Protocol

Showing statistics of only TCP protocol by using option netstat -st.

# netstat -st

Tcp:
 2805201 active connections openings
 1597466 passive connection openings
 1522484 failed connection attempts
 37806 connection resets received
 1 connections established
 57718706 segments received
 64280042 segments send out
 3135688 segments retransmited
 74 bad segments received.
 17580 resets sent



  1. Showing Statistics by UDP Protocol
# netstat -su

Udp:
 1774823 packets received
 901848 packets to unknown port received.
 0 packet receive errors
 2968722 packets sent



  1. Displaying Service name with PID

Displaying service name with their PID number, using option netstat -tp will display “PID/Program Name”.

# netstat -tp

Active Internet connections (w/o servers)
 Proto Recv-Q Send-Q Local Address               Foreign Address             State       PID/Program name
 tcp        0      0 192.168.0.2:ssh             192.168.0.1:egs             ESTABLISHED 2179/sshd
 tcp        1      0 192.168.0.2:59292           www.gov.com:http            CLOSE_WAIT  1939/clock-applet



  1. Displaying Promiscuous Mode

Displaying Promiscuous mode with -ac switch, netstat print the selected information or refresh screen every five second. Default screen refresh in every second.

# netstat -ac 5 | grep tcp

tcp        0      0 *:sunrpc                    *:*                         LISTEN
 tcp        0      0 *:58642                     *:*                         LISTEN
 tcp        0      0 *:ssh                       *:*                         LISTEN
 tcp        0      0 localhost:ipp               *:*                         LISTEN
 tcp        0      0 localhost:smtp              *:*                         LISTEN
 tcp        1      0 192.168.0.2:59447           www.gov.com:http            CLOSE_WAIT
 tcp        0     52 192.168.0.2:ssh             192.168.0.1:egs             ESTABLISHED
 tcp        0      0 *:sunrpc                    *:*                         LISTEN
 tcp        0      0 *:ssh                       *:*                         LISTEN
 tcp        0      0 localhost:ipp               *:*                         LISTEN
 tcp        0      0 localhost:smtp              *:*                         LISTEN
 tcp        0      0 *:59482                     *:*                         LISTEN



  1. Displaying Kernel IP routing

Display Kernel IP routing table with netstat and route command.

# netstat -r

Kernel IP routing table
 Destination     Gateway         Genmask         Flags   MSS Window  irtt Iface
 192.168.0.0     *               255.255.255.0   U         0 0          0 eth0
 link-local      *               255.255.0.0     U         0 0          0 eth0
 default         192.168.0.1     0.0.0.0         UG        0 0          0 eth0



  1. Showing Network Interface Transactions

Showing network interface packet transactions including both transferring and receiving packets with MTU size.

# netstat -i

Kernel Interface table
 Iface       MTU Met    RX-OK RX-ERR RX-DRP RX-OVR    TX-OK TX-ERR TX-DRP TX-OVR Flg
 eth0       1500   0     4459      0      0      0     4057      0      0      0 BMRU
 lo        16436   0        8      0      0      0        8      0      0      0 LRU



  1. Showing Kernel Interface Table

Showing Kernel interface table, similar to ifconfig command.

# netstat -ie

Kernel Interface table
 eth0      Link encap:Ethernet  HWaddr 00:0C:29:B4:DA:21
 inet addr:192.168.0.2  Bcast:192.168.0.255  Mask:255.255.255.0
 inet6 addr: fe80::20c:29ff:feb4:da21/64 Scope:Link
 UP BROADCAST RUNNING MULTICAST  MTU:1500  Metric:1
 RX packets:4486 errors:0 dropped:0 overruns:0 frame:0
 TX packets:4077 errors:0 dropped:0 overruns:0 carrier:0
 collisions:0 txqueuelen:1000
 RX bytes:2720253 (2.5 MiB)  TX bytes:1161745 (1.1 MiB)
 Interrupt:18 Base address:0x2000

lo        Link encap:Local Loopback
 inet addr:127.0.0.1  Mask:255.0.0.0
 inet6 addr: ::1/128 Scope:Host
 UP LOOPBACK RUNNING  MTU:16436  Metric:1
 RX packets:8 errors:0 dropped:0 overruns:0 frame:0
 TX packets:8 errors:0 dropped:0 overruns:0 carrier:0
 collisions:0 txqueuelen:0
 RX bytes:480 (480.0 b)  TX bytes:480 (480.0 b)



  1. Displaying IPv4 and IPv6 Information

Displays multicast group membership information for both IPv4 and IPv6.

# netstat -g

IPv6/IPv4 Group Memberships
 Interface       RefCnt Group
 --------------- ------ ---------------------
 lo              1      all-systems.mcast.net
 eth0            1      224.0.0.251
 eth0            1      all-systems.mcast.net
 lo              1      ff02::1
 eth0            1      ff02::202
 eth0            1      ff02::1:ffb4:da21
 eth0            1      ff02::1



  1. Print Netstat Information Continuously

To get netstat information every few second, then use the following command, it will print netstat information continuously, say every few seconds.

# netstat -c

Active Internet connections (w/o servers)
 Proto Recv-Q Send-Q Local Address               Foreign Address             State
 tcp        0      0 tecmint.com:http   sg2nlhg007.shr.prod.s:36944 TIME_WAIT
 tcp        0      0 tecmint.com:http   sg2nlhg010.shr.prod.s:42110 TIME_WAIT
 tcp        0    132 tecmint.com:ssh    115.113.134.3.static-:64662 ESTABLISHED
 tcp        0      0 tecmint.com:http   crawl-66-249-71-240.g:41166 TIME_WAIT
 tcp        0      0 localhost.localdomain:54823 localhost.localdomain:smtp  TIME_WAIT
 tcp        0      0 localhost.localdomain:54822 localhost.localdomain:smtp  TIME_WAIT
 tcp        0      0 tecmint.com:http   sg2nlhg010.shr.prod.s:42091 TIME_WAIT
 tcp        0      0 tecmint.com:http   sg2nlhg007.shr.prod.s:36998 TIME_WAIT



  1. Finding non supportive Address

Finding un-configured address families with some useful information.

# netstat --verbose

netstat: no support for `AF IPX' on this system.
 netstat: no support for `AF AX25' on this system.
 netstat: no support for `AF X25' on this system.
 netstat: no support for `AF NETROM' on this system.



  1. Finding Listening Programs

Find out how many listening programs running on a port.

# netstat -ap | grep http

tcp        0      0 *:http                      *:*                         LISTEN      9056/httpd
 tcp        0      0 *:https                     *:*                         LISTEN      9056/httpd
 tcp        0      0 tecmint.com:http   sg2nlhg008.shr.prod.s:35248 TIME_WAIT   -
 tcp        0      0 tecmint.com:http   sg2nlhg007.shr.prod.s:57783 TIME_WAIT   -
 tcp        0      0 tecmint.com:http   sg2nlhg007.shr.prod.s:57769 TIME_WAIT   -
 tcp        0      0 tecmint.com:http   sg2nlhg008.shr.prod.s:35270 TIME_WAIT   -
 tcp        0      0 tecmint.com:http   sg2nlhg009.shr.prod.s:41637 TIME_WAIT   -
 tcp        0      0 tecmint.com:http   sg2nlhg009.shr.prod.s:41614 TIME_WAIT   -
 unix  2      [ ]         STREAM     CONNECTED     88586726 10394/httpd



  1. Displaying RAW Network Statistics
# netstat --statistics --raw

Ip:
 62175683 total packets received
 52970 with invalid addresses
 0 forwarded
 Icmp:
 875519 ICMP messages received
 destination unreachable: 901671
 echo request: 8
 echo replies: 16253
 IcmpMsg:
 InType0: 83
 IpExt:
 InMcastPkts: 117

5 COMMENTS

  1. I’ve earned $104k in last 12 months by doing an online job a­­n­­d I manage to do it by wor­king part-time for 3+ h each day. I’m using a money making opportunity I came across from company that i found online and I am so happy that i was able to make so much money. It’s so newbie-friendly and I’m so happy that i discovered this. Check out what I do… http://itreplaceitall­.­com

  2. I was paid 104000 dollars last 12 month period by doing a web-based work furthermore I was able to do it by w­orking in my own time f­o­r quite a few hours on a daily basis. I used work opportunity I came across on-line and also I am excited that I was able to earn such decent earnings. It is genuinely newbie-friendly and therefore I’m so blessed that I found out regarding it. Look out for exactly what I do… http://secure10­.­weebly­.­com

  3. M­a­n­y p­e­o­ple w­a­nt t­o ha­v­e a passive earnings at h­o­me, bu­t t­he­y do­n’t kno­w ho­w t­o exactly d­o th­at o­n th­e Int­ernet. Th­ere ar­e a l­ot of w­ays t­o ea­rn significant am­ount of mo­ney, b­ut wh­enev­er p­eopl­e t­ry th­at the­y g­et tr­app­ed in a s­cam, So I am sh­aring wi­th yo­u a g­enuine an­d gu­arante­ed w­ay f­or fre­e to ea­rn hug­e am­ount of mon­ey a­t ho­me.I am making atleast $10000 on a monthly basis since a year.Its an internet based work and also very simple to do, Even a little boy or girl can do this work and make online money. If you want a happy and rich life then you should copy and paste this site in browser and then follow instructions to get started today and earn Thousands On the internet……….. http://s­.­id/1cn

  4. M­a­n­y p­e­o­ple wish t­o ha­v­e a passive in­com­e at their, bu­t t­he­y don’t have much idea ho­w t­o exactly d­o th­at o­n th­e Int­ernet. Th­ere ar­e a many w­ays t­o ea­rn big am­ount of mo­ney, b­ut wh­enev­er p­eopl­e t­ry th­at the­y g­et tr­app­ed in a s­cam, And so I am sh­aring wi­th yo­u a g­enuine an­d gu­arante­ed w­ay f­or fre­e to ea­rn hug­e am­ount of mon­ey a­t ho­me.I am earning atleast $10000 per month since a whole year.Its on-line job and also quite easy to do, Even a little child can do this work and make money on the internet. If you want a happy and wealthy life then you should copy and paste this internet site in browser and then follow instructions to get started right now and earn Thousands Using the internet……….. http://shrty­.­link/PWmuqJ

LEAVE A REPLY

Please enter your comment!
Please enter your name here
