This is a guest post written by Alex Rodriguez.

About the Author

Alex Rodriguez is a Linux dev-ops administrator, running Puppet to manage a SaaS platform of approximately 70 Linux servers. The great majority of them are virtualized hosts running CentOS 6.3-6.5 on XenServer 6.2.0 hypervisor; meaning he had approximately 15 bare metal XenServers to be manage manually; a sacrilege, once you get used to Puppet ;)

Contact the Author: alex@mengano.net

Prerequisites

Requirements, not covered on this article:

  • Puppet server installed and configured, including proper manifests, plug-ins, etc.
  • XenServer 6.2.0 hypervisor properly configured and optionally a member of a Xen Pool.

Environment

Puppet server: “puppet01”

[root@puppet01:/tmp]# uname -a
Linux puppet01 2.6.32-358.14.1.el6.x86_64 #1 SMP Tue Jul 16 23:51:20 UTC 2013 x86_64 x86_64 x86_64 GNU/Linux
[root@puppet01:/tmp]#
[root@puppet01:/tmp]# cat /etc/redhat-release
CentOS release 6.4 (Final)
[root@puppet01:/tmp]#

[root@puppet01:/tmp]# facter $serverversion
architecture => x86_64
…
kernel => Linux
kernelmajversion => 2.6
kernelrelease => 2.6.32-358.14.1.el6.x86_64
…
puppetversion => 3.2.3

XenServer 6.2.0 hypervisor: “xen01”

[root@xen01 ~]# xe host-list params=name-description,software-version
name-description ( RW)    : Default install of XenServer
    software-version (MRO): product_version: 6.2.0; product_version_text: 6.2; product_version_text_short: 6.2; platform_name: XCP; platform_version: 1.8.0; product_brand: XenServer; build_number: 70446c; hostname: othone-2; date: 2013-06-21; dbv: 2013.0621; xapi: 1.3; xen: 4.1.5; linux: 2.6.32.43-0.4.1.xs1.8.0.839.170780xen; xencenter_min: 2.0; xencenter_max: 2.0; network_backend: openvswitch; xs:xenserver-transfer-vm: XenServer Transfer VM, version 6.2.0, build 70314c; xs:main: XenServer Pack, version 6.2.0, build 70446c; xcp:main: Base Pack, version 1.8.0, build 70446c
[root@xen01 ~]#

Procedure

Install Puppet client On XenServer:

Install dependent EPEL and PuppetLabs YUM repos:

[root@xen01 tmp]# wget http://dl.fedoraproject.org/pub/epel/5/$(uname -i)/epel-release-5-4.noarch.rp
[root@xen01 tmp]#
[root@xen01 tmp]# rpm -Uvh epel-release-5-4.noarch.rpm
Preparing...                ########################################### [100%]
   1:epel-release
[root@xen01 tmp]# wget https://yum.puppetlabs.com/el/5/products/i386/puppetlabs-release-5-7.noarch.rpm

[root@xen01 tmp]# rpm -Uvh /tmp/ puppetlabs-release-5-7.noarch.rpm
Preparing...                ########################################### [100%]
   1:puppetlabs-release     ########################################### [100%]
 [root@xen01 tmp]#

XenServer 6.2.0 is based on CentOS, thus is has CentOS yum repository configuration, it just needs to be enabled

[root@xen01 tmp]# sed -i 's/enabled=1/enabled=0/g' /etc/yum.repos.d/CentOS-Base.repo

Install puppet client:

[root@xen01 tmp]# yum install puppet-3.2.3-1.el5
…
Dependencies Resolved

=============================================================================================================================================================================
 Package                                      Arch                            Version                                     Repository                                    Size
=============================================================================================================================================================================
Installing:
 puppet                                       noarch                          3.2.3-1.el5                                 puppetlabs-products                          1.0 M
Installing for dependencies:
 augeas-libs                                  i386                            0.10.0-4.el5                                puppetlabs-deps                              373 k
 facter                                       i386                            1:1.7.5-1.el5                               puppetlabs-products                           87 k
 hiera                                        noarch                          1.3.2-1.el5                                 puppetlabs-products                           23 k
 libX11                                       i386                            1.0.3-11.el5_7.1                            base                                         797 k
 libXau                                       i386                            1.0.1-3.1                                   base                                          18 k
 libXdmcp                                     i386                            1.0.1-2.1                                   base                                          19 k
 libselinux-ruby                              i386                            1.33.4-5.7.el5                              base                                          60 k
 ruby                                         i386                            1.8.7.374-2.el5                             puppetlabs-deps                              379 k
 ruby-augeas                                  i386                            0.4.1-3.el5                                 puppetlabs-deps                               22 k
 ruby-irb                                     i386                            1.8.7.374-2.el5                             puppetlabs-deps                              343 k
 ruby-libs                                    i386                            1.8.7.374-2.el5                             puppetlabs-deps                              2.2 M
 ruby-rdoc                                    i386                            1.8.7.374-2.el5                             puppetlabs-deps                              411 k
 ruby-rgen                                    noarch                          0.6.5-2.el5                                 puppetlabs-deps                              349 k
 ruby-shadow                                  i386                            1:2.2.0-2.el5                               puppetlabs-deps                               13 k
 rubygem-json                                 i386                            1.5.5-2.el5                                 puppetlabs-deps                              772 k
 rubygems                                     noarch                          1.3.7-1.el5                                 puppetlabs-deps                              217 k
 tk                                           i386                            8.4.13-5.el5_1.1                            base                                         888 k
 virt-what                                    i386                            1.11-2.el5                                  base                                          23 k
 xorg-x11-filesystem                          noarch                          7.1-2.fc6                                   base                                         5.4 k

Transaction Summary
=============================================================================================================================================================================
Install      20 Package(s)
Upgrade       0 Package(s)

Total download size: 7.9 M
Is this ok [y/N]:

(20/20): ruby-libs-1.8.7.374-2.el5.i386.rpm                                                                                                                                                                           | 2.2 MB     00:01
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Total                                                                                                                                                                                                        1.1 MB/s | 7.9 MB     00:07
warning: rpmts_HdrFromFdno: Header V3 RSA/SHA1 signature: NOKEY, key ID 4bd6ec30
puppetlabs-products/gpgkey                                                                                                                                                                                            | 1.7 kB     00:00
Importing GPG key 0x4BD6EC30 "Puppet Labs Release Key (Puppet Labs Release Key) <info@puppetlabs.com>" from /etc/pki/rpm-gpg/RPM-GPG-KEY-puppetlabs
Is this ok [y/N]: y

Installed:
  puppet.noarch 0:3.2.3-1.el5

Dependency Installed:
  augeas-libs.i386 0:1.1.0-1.el5               facter.i386 1:2.0.1-1.el5            hiera.noarch 0:1.3.2-1.el5            libX11.i386 0:1.0.3-11.el5_7.1        libXau.i386 0:1.0.1-3.1                libXdmcp.i386 0:1.0.1-2.1
  libselinux-ruby.i386 0:1.33.4-5.7.el5        ruby.i386 0:1.8.7.374-2.el5          ruby-augeas.i386 0:0.4.1-3.el5        ruby-irb.i386 0:1.8.7.374-2.el5       ruby-libs.i386 0:1.8.7.374-2.el5       ruby-rdoc.i386 0:1.8.7.374-2.el5
  ruby-rgen.noarch 0:0.6.5-2.el5               ruby-shadow.i386 1:2.2.0-2.el5       rubygem-json.i386 0:1.5.5-2.el5       rubygems.noarch 0:1.3.7-1.el5         tk.i386 0:8.4.13-5.el5_1.1             virt-what.i386 0:1.11-2.el5
  xorg-x11-filesystem.noarch 0:7.1-2.fc6

Complete!
[root@xen01 tmp]#

Configure new Puppet node

On Puppet server, define the new node.

NOTE: Here I’m sub-classing a couple of puppet classes we have. I will include needed excerpts of each at the bottom.

Add node definition on Puppet server’s site.pp file or main manifest file.

node xenserver {
  include common_xen
}
…
node xen01 inherits xenserver {
}

On XenServer, add Puppet server configuration to /etc/puppet/puppet.conf, like so:

[root@xen01 ~]# grep server /etc/puppet/puppet.conf
    # Puppet server
    server = puppet01
[root@xen01 ~]#

On XenServer, set auto start puppet on boot-up:

[root@xen01 ~]# chkconfig puppet on
[root@xen01 ~]#

… and start the Puppet client:

[root@xen01 ~]# /etc/init.d/puppet start
Starting puppet agent:                                     [  OK  ]
[root@xen01 ~]#

A few seconds after you start Puppet client on XenServer, you should see a certificate sign request on Puppet server. Confirm receipt of such request and sign certificate like so:

[root@puppet01:/etc/puppet]# puppet cert --list
  "xen01 " (SHA256) B5:2C:87:D1:C9:D0:BE:42:F0:26:A5:CB:73:61:DA:43:C9:00:BA:21:C7:CA:5E:5A:BC:9D:9F:47:5F:61:2E:81
[root@puppet01:/etc/puppet]#
[root@puppet01:/etc/puppet]# puppet cert --sign xen01
Notice: Signed certificate request for xen01
Notice: Removing file Puppet::SSL::CertificateRequest xen01 at '/var/lib/puppet/ssl/ca/requests/1xen01.pem'
[root@puppet01:/etc/puppet]#

Verification

Run Puppet client manually to verify Puppet server logs client request and client properly downloads its catalog:

[root@xen01 ~]# puppet agent --verbose --onetime --no-daemonize --splaylimit 1
Info: Retrieving plugin
Info: Loading facts in /var/lib/puppet/lib/facter/fstab.rb
Info: Caching catalog for xen01
Info: Applying configuration version '1396311876'
…
Notice: /Group[atlassian]/ensure: created
Notice: /Group[staging]/ensure: created
Notice: /Group[production]/ensure: created
…
Notice: Finished catalog run in 2.51 seconds
[root@xen01 ~]#

Verify Puppet server logs XenServer node receiving its catalog:

Mar 31 17:19:39 puppet01 puppet-master[30395]: (Scope(Node[default]))  xen01 - XenServer 2.6.32.43-0.4.1.xs1.8.0.839.170780xen - puppet: 3.2.3
Mar 31 17:20:01 puppet01 puppet-master[30395]:

Excerpts of needed Puppet manifests

common_xen.pp manifest

class common_xen {

include postfix

      # Packages
     package { "epel-release": ensure => "installed" }
      package { "puppetlabs-release": ensure => installed }
      package { "yum-utils": ensure => installed }
      package { "facter": ensure => installed }
      package { "puppet": ensure => "3.2.3-1.el5" }

      exec { "mta-alternative":
            command => "/usr/sbin/alternatives --set mta /usr/sbin/sendmail.postfix",
            #unless => "/usr/bin/test -f /usr/sbin/sendmail.postfix",
            path => "/bin/:/usr/bin",
            require => Package[ "postfix" ],
      }

      # Puppet
      service { "puppet":
        ensure => running,
        enable => true,
        hasrestart => true,
        hasstatus => true,
      }
}

postfix.pp manifest

class postfix {

        package { "sendmail-cf": ensure => absent }
        package { "sendmail": ensure => absent }
        package { "postfix": ensure => installed }
        package { "mailx": ensure => installed }

        service { "postfix":
                ensure => running,
                enable => true,
                hasrestart => true,
                hasstatus => true,
                require => [ File["main.cf"], Package["postfix"] ]
        }

}

Cheers!
